2100 Series

Category: Tag:

This highly attractive and very economical NSF Approved medium-duty caster features a cast aluminium double-lock braking system.

Download Catalogue Page

Description

This highly attractive and very economical medium-duty caster features a cast aluminium double-lock braking system. The system simultaneously locks the wheel and swivel head. One step on the cast metal pedal instantly locks the entire caster holding equipment firmly in place. One step on this economical medium-duty caster pedal releases the swivel and wheel with ease.

The 2100 Series is moisture friendly with a plastic seal that protects the raceway.

The 2100 Series is NSF Approved.

Options/Components: Available with a number of wheels including our RollXâ„¢, ProTechâ„¢ and Envirothaneâ„¢. This caster can be configured with ball bearings, precision ball bearings and roller bearings as well as a variety of stem choices.

Ideal Applications: Metal Fabrications, Schools, Libraries, Audio & Visual Aid Equipment.

NSF Component Certified

Additional information

Wheel Diameter
Wheel Type Envirothaneâ„¢, Hard Rubber, Lavaâ„¢, Moldon Alum. Rubber, Moldon Poly. Urethane (PLY), Phenolic, Polyolefin, Protechâ„¢ Flat, Retortâ„¢, RollXâ„¢, Soft Rubber
Bushing , , ,
Bearings Ball Bearing, Precision Ball Bearing, Roller Bearing
Leg Spacing
Axle & Nut
Kingpin
Raceway
Stems , , ,
Plates A25D, A27D
Finish , , ,
Brakes
Options , , , ,
STANDARD SWIVEL PLATE: A25D STANDARD SWIVEL PLATE: A27D
Expandable Round Stems
*** Diameter Length Type
3/4RDEXP 3/4" 3 1/8" Rubber
7/8RDEXP 7/8" 3 1/8" Rubber
1RDEXP 1" 4 1/4" Rubber
1 1/8RDEXP 1 1/8" 4 1/4" Rubber
1 3/8RDEXP 1 3/8" 4 1/4" Rubber
1 1/2RDEXP 1 1/2" 4 1/4" Rubber
Expandable Square Stems
*** Diameter Length Type
3/4SQEXP 3/4" 3 1/8" Rubber
7/8SQEXP 7/8" 3 1/8" Rubber
1SQEXP 1" 4 1/4" Rubber
1 1/8SQEXP 1 1/8" 4 1/4" Rubber
1 1/4SQEXP 1 1/4" 4 1/4" Rubber
1 3/8SQEXP 1 3/8" 4 1/4" Rubber
1 1/2SQEXP 1 1/2" 4 1/4" Rubber
Special Threads
*** Diameter Length
5/16– ** X length HO 5/16" Any
3/8– ** X length HO 3/8" Any
1/2– ** X length HO 1/2" Any
Bolt Holes
*** Diameter
5/16HOLE 5/16"
3/8HOLE 3/8"
1/2HOLE 1/2"


2100 Series Specifications & Part Numbers

1 (800) 254-6633
service@algood.com

Algood Casters has manufactured, designed and developed industrial and specialty casters, brakes and wheels since 1969, in capacities from 25 to 65,000 lbs.
