Typhoon9™ Series

The kingpinless design of the Typhoon9™ Series makes this stainless-steel caster virtually indestructible and ideal for high-impact, heavy-duty applications.

Download Catalogue Page

Description

The head of the Typhoon9™ Series is welded directly to the plate making it just about indestructible. That ruggedness and durability makes it ideal for high-impact, heavy-duty or high-temperature applications. And with its stainless-steel construction, it’s suitable for wet or dry as well as indoor or outdoor applications.

Kingpinless casters are more rugged and can carry heavier loads than casters with a kingpin. The kingpinless design is simpler, consisting of a machined raceway attached to the legs. With kingpinless casters, the load is spread over a much larger area, making them more stable.

The Typhoon9™ Series brake options include a PolyCam, thumb screw, side-locking, and a universal wheel brake as well as a four-position swivel lock.

This mighty caster is made from work-hardened, electro-polished, de-magnetized and de-burred SAE 304 stainless steel.

Options/Components: Can be equipped with stainless components like ball bearings, plates and stems as well as an optional stainless steel PolyCam brake.

Ideal Applications: Abusive, High-Impact, Heavy-Duty Applications. Hospitals, Healthcare, Pharmaceutical, Food Preparation, High-Tech & Clean Environments.

Made in North America

Additional information

Wheel Diameter
Wheel Type 304 (304), Lava™, NyRock™, Phenolic, RollX™, V Groove 304
Bushing
Bearings Delrin Bearing, Stainless Steel Ball Bearing, Stainless Steel Precision Ball Bearing, Stainless Steel Roller Bearing
Leg Spacing
Axle & Nut
Kingpin
Raceway
Lubrication
Plates A46I, A50I, A52I, A55I, A58I
Finish
Brakes , ,
Options
STANDARD PLATE: A52I OPTIONAL PLATE: A46I
OPTIONAL PLATE: A50I OPTIONAL PLATE: A55I
OPTIONAL PLATE: A58I


Typhoon9 Series Specifications & Part Numbers
